百分内径量表
型号: 2322/2122
符合JJF内径表国家计量技术规范
测头和测砧为陶瓷材质(其中测量范围18-35mm的测头为钢材质)
| 型号 | 测量范围 | 精度 | 重复精度 |
|---|---|---|---|
| 2322-35AC | 18-35mm | ±0.015mm | 0.003mm |
| 2322-60AC | 35-60mm | ±0.018mm | 0.003mm |
| 2322-100AC | 50-100mm | ±0.018mm | 0.003mm |
| 2322-160AC | 50-160mm | ±0.018mm | 0.003mm |
| 2322-161AC | 100-160mm | ±0.018mm | 0.003mm |
| 2322-250AC | 160-250mm | ±0.018mm | 0.003mm |
| 2322-450AC | 250-450mm | ±0.018mm | 0.003mm |
| 2122-35A | 18-35mm | ±0.015mm | 0.003mm |
| 2122-60A | 35-60mm | 0.003mm | 0.003mm |
| 2122-100A | 50-100mm | 0.003mm | 0.003mm |
| 2122-160A | 50-160mm | 0.003mm | 0.003mm |
| 2122-161A | 100-160mm | 0.003mm | 0.003mm |
| 2122-250A | 160-250mm | 0.003mm | 0.003mm |
| 2122-450A | 250-450mm | 0.003mm | 0.003mm |
| 2122-35AWP | 18-35mm | ±0.015mm | 0.003mm |
| 2122-60AWP | 35-60mm | 0.003mm | 0.003mm |
| 2122-100AWP | 50-100mm | 0.003mm | 0.003mm |
| 2122-160AWP | 50-160mm | 0.003mm | 0.003mm |
| 2122-161AWP | 100-160mm | 0.003mm | 0.003mm |
| 2122-250AWP | 160-250mm | 0.003mm | 0.003mm |
| 2122-450AWP | 250-450mm | 0.003mm | 0.003mm |
