数据传输
Code: 3561
符合JJG外径千分尺国家计量检定规程
用于测量管子的壁厚
分辨率: 0.001mm/0.00005"
防尘/防水等级: IP65
按键: 开/关, 初始值设置, 公/英制转换, 数据输出
数据传输, 自动关机, 棘轮测力
测杆头部测量面为硬质合金
配标准杆(除0-25mm/0-1"外)
电源:
| Code | Range | Accuracy | Resolution | Type | Data output |
|---|---|---|---|---|---|
| 3561-25A | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | A | with data interface |
| 3561-50A | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | A | with data interface |
| 3561-25BA | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | B | with data interface |
| 3561-50BA | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | B | with data interface |
| 3561-25CA | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | C | with data interface |
| 3561-50CA | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | C | with data interface |
| 3561-25DA | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | D | with data interface |
| 3561-50DA | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | D | with data interface |
| 3561-25EA | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | E | with data interface |
| 3561-50EA | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | E | with data interface |
| 3561-25FA | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | F | with data interface |
| 3561-50FA | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | F | with data interface |
| 3561-25AWL | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | A | built-in wireless |
| 3561-50AWL | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | A | built-in wireless |
| 3561-25BAWL | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | B | built-in wireless |
| 3561-50BAWL | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | B | built-in wireless |
| 3561-25CAWL | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | C | built-in wireless |
| 3561-50CAWL | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | C | built-in wireless |
| 3561-25DAWL | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | D | built-in wireless |
| 3561-50DAWL | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | D | built-in wireless |
| 3561-25EAWL | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | E | built-in wireless |
| 3561-50EAWL | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | E | built-in wireless |
| 3561-25FAWL | 0-25mm/0-1" | ±6μm | 0.001mm/0.00005" | F | built-in wireless |
| 3561-50FAWL | 25-50mm/1-2" | ±6μm | 0.001mm/0.00005" | F | built-in wireless |
View the complete
product specifications
